Fuel Grade Identification to EN 16942 for ZVA Nozzles
Type EK FGI - attach with Product Badge EK 145
EA 866 scuffguard orange with ZVG 2 ACME nozzle
The scuffguard for LPG / Autogas nozzles shows the LPG fuel grade marking required by standard, and offers a large advertising space
Dantec Production hose
Composite hoses: hose with customer braning, application of outer helix
Solvapal hose assemblies
Solvents
VX 75-3" Ms
Male hose coupling 3" BSP of brass with Spannfix clamp
ZVA Slimline 2 nozzles special version, Slimline dispensing hoses blue / red
Thailand
IBC unloading
Coupling of chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-reducer RS 60 x 2 SS, directly attached to IBC.
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
ERV-W 80.16 SS TA
White Band Rubber Expansion Joint with "TA" PTFE lining
Ferrule threaded hose coupling M 25-1" SS
for petrol station dispensing hoses, chemical hoses, AdBlue® urea solution
Requirements to a Hose
(English)
UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS
Production MannTek, Sweden
V 19-1"
Male ferrule hose coupling EN 14424, reusable. Slimline 19 hose, black.
Elaflex Pacific (Australia)
Manufacturing GasGuard GG1 nozzle
Terminal Railtanker
LTW 100, MK 100, VK 100, SBC 100-4, FFBV 100
Fluorline EFL 16
Universal pump hose DN 16 for chemicals, petroleum based products, for propane, butane and other L.P. gases, as well as solvents. Ideal for highly sensitive media such as AdBlue® urea solution. Temperature range -40 °C to +100 °C. Burst pressure > 64 bar.
Cabinet of road tanker:
MK 80 with VB 80 ADR SS (plug with pressure relief)
Equipment truck for dangerous goods accidents, Elaflon PTFE universal hose assembly, DDC Dry Disconnect Coupling
Fuel delivery at the petrol station
LTW 75 fuel delivery hose
Unloading LNG road tanker
DCC Dry Cryogenic Coupling
ERV VSRV:
ERV with bolted vacuum support ring. For maximal vacuum resistance of the selected ERV. Bolted ring in stainless steel AISI 316 Ti.
Ball Valve 350 bar
for Hydrogen
ZVA Slimline 2 for aircraft refuelling
black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly
Oasis FV103 45° Fill Valve, for CNG
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (English)
NB-ZVF 50 SR, ER 583 PTL, HD-C 38
Nozzle boot f. ZVF 50 with additional spout retainer
GasGuard LPG nozzle GG1E
eoconomic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.
Camlock couplings:
stainless steel female and male couplings to EN 14420 - 7
H2 Hydrogen
H2 25 D Hydrogen hose, SFC 25, MX 25, VH 2
