Elaflon PTFE
Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.
Cargo loading of a tanker with petroleum based products; FHD hose assembly
Picture courtesy of Macoil International, Gibraltar
LNG Refuelling
LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, vent hose assenbly with 'VC-LNG'
ELAFLEX Hamburg
Hose stock, reeling up a FEP hose
ELAFLEX hose quality: braided reinforcements
serve for flexibility, low weight and increased lifetime
ELAFLEX Hamburg
Construction
ZVG 2 ACME nozzle for L.P. Gas / Autogas, LPG 16 hose assembly, ARK 19 Safety Break
ERV Fire Resistance test
ZAF Coax adapter (splitter valve) at petrol station dispenser
MK 80-2" AG
TW female coupler, brass, with reduced male thread (special type)
ZVA Slimline 2 nozzles with splashguard, Slimline hose assemblies
Refuelling at a petrol station in the United Arab Emirates
LTW 75 hose assembly
with MKX 75.80 Ms
GasGuard LPG nozzle GG20DN
With long connector nut to access 'hard to reach' fill points. "DN": suited for use by the general public and untrained personell (self service). Patented dual nose piece for added safety. Low lever actuation force. Gas release volume on valve closure : 1,7 cm³.
ELAFLEX Hamburg
ERV inner protection sleeve/tube "SR"
DDC-K 2 1/2" PE
Dust cap for DDC-V Dry Disconnect Couplings;
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation
ZVG 2 ACME nozzle for L.P. Gas / Autogas
pulling lever and latching, possible with one hand
SMX 50-2"
Female hose coupling of steel with Spannfix clamps
COAX Safety Break
CSB 21
Airfield fixinstallation: Hose Reels JET, AVGAS
Type HD-C, aviation hose, ZVA 32
Tank truck and trailer with HD 45 hose reel, ZV 500 nozzle
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
Elaflex hoses
PTFE, FEP, HD, UTS
LH2 Refuelling
'N-LH2' nozzle for LH2 truck refuelling of cryogenic hydrogen
ZVF 50 JET
with HD-C NEON hose assembly
UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS
Construction site / on site refuelling:
ZVA 25 (automatic nozzle), road tanker
ZVF 50 JET overwing refuelling
with HD-C hose assembly
Ship loading with chemicals
UTS 150 hose assembly, ARK-S Safety Break Coupling
Hose Beads
BD 50, BD 63
