DDC-K 3" Al ADR with pressure relief

Cap for DDC-V 80
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation

ZV 500

High performance manual operated dispensing nozzle with 'TW' coupling MK 50 for Diesel, fuel, oils, petroleum

Boat refuelling

ZVA Slimline 25, HD hose assembly

Dantec Production hose

Composite hoses

Road tanker Sweden

large reel with HD hose assembly, DDC-V (Dry Disconnect Coupling, tank unit) and DDC-K (caps)

ELAFLEX Hamburg

Assembling COAX hose SL 21, with inner vapour hose, for vapour recovery Stage II

Slimline 21 blue

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

Hose assembly for petrol stations

Standard hose SL 16

DEC – Dry Evotek Couplings:

dry disconnect couplings for the chemical industry.
• Low connecting forces even against pressure
• Ergonomic handle (DN40 and bigger)
• Good transmission ratio in the cam curve
• Wide range of chemical resistance due to selection of high quality materials
• Minimized spillage during decoupling

ELAFLEX website:

content driven, always current data

TWO 100

TW coupling seal for Tank truck couplings DN 100 to EN 14420-6. NBR black.

Pipe with AVKI 50 SS, hose assembly with AVKX 50 SS, lever movement

'Camlock' stainless steel female and male coupling to EN 14420 - 7

Road tanker with open hose reel, HD hose assembly, ZV 500 nozzle

Hose with SC 50 SS Spannloc stainless steel clamps - corrosion protection against road salt

Pump Safety Break

PSB 16

Hose Connection with TW coupling, TSG 3" Sight Glass

MK 80-32° coupling with bent lever. For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.

Cargo loading of a tanker with petroleum based products; FHD hose assembly

Picture courtesy of Macoil International, Gibraltar

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components (English)

Assembling "ZS" tie rods to ERV rubber expansion joints

ERV-R Red Band rubber expansion joint, ship engine room

Oasis CNG refuelling equipment:

Ultra Fast Fill System (Diagram, English)

Flame protection cover FSH for ERV rubber expansion joints

Slimline dispensing hose SF (sulfur-free)

Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose

ERV-G 80.TW

ERV-G Rubber Expansion Joint with TW flanges DIN 28460 for installation to tankers

Road tanker reel with HD 50 hose assembly, ZV 500 nozzle

Graphic, components of a ZVA Slimline 2 GR nozzle for vapour recovery

UTL 50 universal hose with MannTek Dry Disconnect Coupling

Rubber Expansion Joint ERV-GR 80.16

GREEN BAND expansion joints for chemicals, acids, alkalis and aggressive chemical waste water. For oil-contaminated compressed air up to + 90° C. Temperature range (depending on medium) - 20° C up to + 100° C, temporarily up to + 110° C. Electrically non-conductive.

Universal hose UTS 50

Oasis Engineering Ltd, New Zealand (CNG refuelling products)

Production Picture 3

LNG Refuelling

LNG Nozzle 'N-LNG' coupled to fuel, LNG 25 fill hose assembly, vent hose assenbly with 'VC-LNG'
