Lightweight Gravity Discharge Road Tanker Hose LG 4"
with TW coupling (VK 100)
Universal hose assembly for vehicles fighting dangerous goods incidents:
PTFE 50, length 5 mtr., assembled with MKX 50 SS/Vi SS, VKX 50 SS/Vi SS
PAL hose assemblies:
PCD 32 / RMC-SS, Butapal 32 / ACMX, Polypal Plus 50 / SFC 50 SS, Tecnopal 38 / MKX-SS, Pyropal 38 / MC38
ZVA Slimline 2 and ZVA Slimline 2 GR, Slimline hose assemblies
Petrol station, Indonesia
Anti-Kinking Spirals 'KSS' and 'KSS-SD'
The main bending stress area for hose assemblies is directly behind the coupling. To reinforce this area we developed the Anti-Kinking Spiral 'KSS': suitable for all ELAFLEX hoses, recommended for dynamically strong stressed universal hoses with thermoplastic linings
LNG Refuelling
LNG truck refuelling with 'N-LNG' Nozzle coupled to fuel, LNG 25 fill hose assembly with cover, bonding cable
Terminal / gantry: TW hose assemblies for bottom loading of road tankers
ERV-R 80.16 SS TA
Red Band Rubber Expansion Joint with "TA" PTFE lining
ERV-G Yellow Band rubber expansion joints, pumping system for oil emulsion
M 21-1" cr
Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, red.
ERV-R
"Red Band" Rubber Expansion Joints / ship engine room
MK-A 80 SS, TW female coupler with Active Safeguard Lever
connected: hose assembly with VKX 75.80 SS
Nozzles and hose assemblies for the forecourt
ZVA Slimline 2, ZVA Slimline 2 GR, Slimline hose assemblies
Hose assemblies for petroleum based products
Yellow Band quality with nozzle, TW coupling, flange connection
ERV-G rubber expansion joint
ERV-G AF DN 80, with TW flanges
ELAFLEX Tanktechnik, Production Plettenberg / Germany
Sand casting ZVA
Hose Reel spring rewind black, FEP 50, DDC-M 50 SS
Chemical manifold
RS 2 x 3 SS
Reducer Female/Male
Road tanker reel with HD 50 hose assembly, ZV 500 nozzle
Hose assemblies for petroleum based procucts
LTW 75, VX 80-3, MannTek DDC-M80-3Ms & TW 63, SFX 63 TW
Road tanker with large reel, HD hose assembly, ZV 500 nozzle
Cargo loading / unloading of ship, STW 150, Vapour Line
Italy
RVX 32-11/4 SS
Hose coupling with male foodstuff thread and Spannfix clamps
DDC-M 80-3" SS
MannTek Dry Disconnect Coupling, DN 80, stainless steel
Production MannTek, Sweden
ERV-R 50.16 ZS 2
Red Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)
ELAPHARM Type EPH
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
Section view of a CSB 21 COAX Safety Break
Nozzle boot NB-ZVF 50
for ZVF 50 Oberflügel-Zapfventile
AN 2 Al
Welding nipple aluminium
