ELAFLEX Hamburg
Hose assemblies pressure testing (hydrostatic test)
Fixed Flange and hose tail of stailess steel
FFC 63.16 SS
ELAFLEX website:
content driven, always current data
VX 63 2½" SS NR Al
Hose coupling with male thread, Spannloc aus Aluminium
Adapter: MK 50-45° SS x VK 50 SS
The lever is bent to enable lever arrest (safe position when coupled)
Fluorflex FXD universal hose assemblies
with inner corrugation for maximal flexibility. Picture 1
ELAFLEX Hamburg
Assembling ERV small DN
Hose Reel with hydraulic rewind system orange, LPG 32, DGC-M 50
ERV-CR
"CR" Rubber Expansion Joints - installation in sewage plant
ELAFLEX Hamburg
Assembling cell dispensing hoses
ELAFLEX Hamburg
Manufacturing bronze corrugated pipes
Oasis Engineering Ltd, New Zealand (CNG refuelling products)
Production Picture 24
DDC-M 50 F Aseptic
MannTek Dry Disconnect Coupling with Aseptic flange
ZVF 50 PTL (Push-Twist-Lock), strainer inspection
Urea solution filling of a car:
ZVA LV for AdBlue®, Slimline 16 for AdBlue® (blue cover)
Hose assemblies
Universal hose UTS 50 with DDC-M 50-2"; Tanker hose for petroleum based products LTW 75 with DDC-M 80-3"
Chemical Hose Reel with manual rewind system blue, UTS 50, ZV 400
for alcohol
ELAFLEX Hamburg
Assembling ERV large DN
Camlock hose couplings: system comparison
Easyloc from Elaflex with automatically secured levers.
ZVA Slimline 2
Automatic nozzle DN 19, for flowrate max. 80 l / min. Green Product Sleeve and Scuffguard, Slimline dispensing hose assembly
Unloading chemical road tanker
UTS hose assembly
Rail tanker unloading of petroleum based products
LTW hose assemblies; Poland
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
ZVG 2 EURO
(Push-In-Coupling) to EN 13760. One-handed operation possible.
Elaflex Tank + Pipe Fittings
RM-St 50 SSE
Female foodstuff threaded hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA
ELAPHARM Type EPH 25
electrically isolating 'I', with blue cover, to EN 16820, Type A. FDA conform, homogeneous elastomer hose construction with smooth, white PTFE liner. Clamp fittings, lining flared (free of dead spaces).
ELAFLEX refuelling equipment:
Quality is in the detail.
Stainless steel couplings with PFA coating, type "...SSE"
Surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.
