Pharma hose fittings
Connection DDC-M 100 with HD hose assembly to tanker
Ship bunkering from the road tanker
Manufacturing of turned parts
Chemical manifold
FEP 5O, MannTek DDC-M 5O SS
LNG Refuelling
N-LNG Nozzle, Soft-Stop-Position
HB 19 ST tar spraying hose
Pressure hose for road construction machines, especially for hot bitumen and heavy heating oil. Temperature range: - 25° C up to + 220° C. Meets EN 13482, Type 2 SB/B (DN 19 and DN 32 analogue).
ELAFLEX Hamburg
Assembling dispensing hose fitting
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
RS 21/2 x3 SS
Reducer Female/Male
ERV-G ... TW
Aircraft refueller
ERV Rubber Expansion Joints
Picture 5
IBC unloading
Coupling of chemical hose assembly with AMKC 50 SS (Camlock female with Spannloc attachment) to AMKI male coupling. Use of IBC-reducer RS 60 x 2 SS, directly attached to IBC.
Slimline 16 blue
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
ZVA Slimline 2 and ZVA Slimline 2 GR, special colour light green
Elaflex petrol station nozzles
Elaflex hoses
FEP, UTS, PCS, HD, LPG, PTFE, CHS
ZVA Slimline 2 GR (vapour recovery nozzle), CSB 21 Coax Safety Break, Coax dispensing hose
DDC-K 2 1/2" PE
Dust cap for DDC-V Dry Disconnect Couplings;
• Meets the ADR requirements
• Enhanced safety and protects the environment
• Easy, user friendly operation
LPG Autogas dispenser
ZVG 2 ACME + ZVG 2 DISH nozzle, LPG 16 hose, ARK 19 Safety Break
ERV SR:
ERV with inner protection sleeve of stainless steel AISI 316 Ti to prevent abrasion of the rubber liner, i. e. for media containing abrasive components or to avoid cavitation. Please note : The nominal bore is reduced.
Terminal Railtanker
LTW 100, MK 100, VK 100, SBC 100-4, FFBV 100
Oasis FV103 45° Fill Valve with NC 104 Nozzle, for CNG
M 21-1" NR cr
Female ferrule hose coupling EN 14424, factory assembled, non-reattacheable. Slimline 21 hose, blue.
MannTek Dry Disconnect Couplings:
DDC-M 80-3" SS with PolypalClean hose assembly, DDC-V 80-3" SS with pipe end
Fixed Flange and hose tail of stailess steel
SFC 63.16 SS
Equipment truck for dangerous goods accidents
suitable hose assemblies and adapters from Elaflex, ELAFLEX_Information_2.17E.pdf
Slimline dispensing hose SF (sulfur-free)
Fuel producers spend considerable effort in fulfilling the maximum allowed sulfur content. Rubber compounds of this hose type are free of sulphur – ensures that the sulphur content of the fuel is not increased, even if the medium remains for a long time within the hose
Unloading petroleum products at the service station (road tanker to UST)
LG 3" hose assembly for gravity discharge, LTW 50 hose assembly for vapour balance
Section view of a DS 2 swivel
ZVF 50 UL 91 / green
Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.
