Bonding Reel grey, high visibility bonding cable

LeverAssist hold-open aid for ZVA Slimline 2 nozzles

Detail

HD-C, airport depot

Underwing couplings with HD-C hoses for bottom loading of aircraft refuellers at airport depot

ERV-GS

"Yellow Steel" Rubber Expansion Joints / ship engine room

DAC-V 65

Aircraft refueller , Dry Aircraft Coupling to ISO 45 for bottom loading

PAL hoses for the chemical industry

SG 1" 1x0 Al

Sight Glass, to EN 13617-1, DN 25, for installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised gasoline and diesel fuels according EN 589 + EN 590, including ethanol or biodiesel content, also Avgas and Jet-A1.

Connection road tanker to trailer: LTW hose assembly, DDC Dry Disconnect Coupling

L.P. Gas rail tanker

loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange

M 21-1" cr

Female ferrule hose coupling EN 14424, reuasable. Slimline 21 hose, blue.

Elaflex Pacific Pty., Australia: workshop

Bellows ERV-GR (Green Band) without flanges, with VSD vakuum support spiral

VSD: to increase vacuum resistance of a chosen ERV type. Open ring of stainless steel 1.4571

Construction of ELAFLEX composite hoses type FWS

Sectioned view of a composite hose, denomination of the components – detail view

ZVA 32 for aircraft refuelling

black plastic cover (scuffguard), Sight Glass, dust cap and ground cable assembly

Manufacturing of turned parts

ZVA Slimline 2, black, guard 3 - side view

SG 1 1x0 SS for Nozzles for AdBlue®

Attach on dispenser side of swivel

GasGuard LPG / Autogas refuelling equipment

Nozzles, nozzle boot for dispenser installation, LPG 16 hose assemblies, Safety Break ARK 19

Ship loading Naphta - STW 150 hose assemblies

Type PCS, Polypal Clean

one side with RMC foodstuff fitting / Spannloc clamps stainless steel, other side open (note the inner conductive stripe)

Ship loading with chemicals

UTS 150 hose assembly, ARK-S Safety Break Coupling

MB 80 SSE

TW dust cap of stainless steel, surface in contact with the medium additionally coated with Teflon® PFA. This type is used if stainless steel does not have a sufficient chemical resistance (i.e. for hydrochloric acid and iron-III-chloride) and polypropylene is not possible because of insufficient stability. Available in all standard sizes.

Slimline quality dispensing hoses for the forecourt

black - yellow - red - blue - green - special colours

ZVF 50 JET

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure 10 bar (140 psi). Temperature range -40° C up to +55° C

Slimline 21 hose assembly with non reattacheable female coupling M 21-1" NR

ELAFLEX Hamburg

ERV inner protection sleeve/tube "SR"

Camlock cam locking couplings

top left – ELAFLEX standard version; bottom right – ELAFLEX EASYLOC version

ERV-GR Green Band rubber expansion joint, Biogas entergy plant

Rubber Expansion Joint ERP 80.16

RED SPOT expansion joints for sanitary installations, highly flexible, for cold and warm water, pool water, sea water, drinking water. Temperature range (depending on medium) - 40° C up to + 90° C, temporarily up to + 120° C. Electrically dissipative.

ZVA Slimline 2 / ZVA Slimline 2 GR

Petrol station nozzles with (top) and without vapour recovery (below)
