Coax hose assembling

ELAFLEX refuelling equipment:

Quality is in the detail.

Manifold at petroleum storage terminal

STW 150 hose assemblies, SFC 150.16 hose flanges

LNG Refuelling

Align N-LNG Nozzle

ZVA Slimline 2 GR

with red scuffguard; CSB 21 Coax Safety Break with BS 21 Break Sleeve; Slimline COAX hose assembly

ZVF 50 JET

Manual aviation fuelling nozzle for overwing service. Flowrate up to 400 ltr. / min. (85 IGM – higher flowrates are possible). Size DN 50. Working pressure PN 10 (140 psi). Temperature range - 40° C up to + 55° C.

Hose assemblies

for saturated steam, chemicals, petroleum based products

VB 50 P, VB 80 P

TW dust plugs of Polyamide

ZVA Slimline 2, SSB 16, Slimline 16 hose assemblies

Maroc, motorcycle refuelling

AMX ammonia hose

rail tanker Loading/Unloading

Example of a marking of test data (hydrostatic test) of a hose assembly

GasGuard LPG nozzle GG20

With long connector nut to access 'hard to reach' fill points. Economic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.

ZVA Slimline 2, black, guard 3 - detail view with new hold-open latch

FFC 50.16 St

Fixed flange hose fitting of steel, with Spannloc clamps

ERV-W 80.16 ZS 2

White Band Rubber Expansion Joint with "ZS" limiter (tie rods with outer limitation in rubber bushings)

Slimline 21 red

Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360 and EN 13483.

ELAFLEX Hamburg

Assembling ERV large DN

Polypal Clean hose assembly

Pharmaceutical production

NR ferrule hose fittings, non reattacheable

ZVA Slimline 2, dispenser

Railtanker

MannTek DDC-V 80 F Dry Disconnect Couplings (tank unit with flange), Pressure Caps PN 25 with pressure relief

Elaflon PTFE 50

Universal hose with electrically conductive, seamless lining of PTFE (Polytetrafluorethylene). Suitable for all commonly used chemicals. Suitable for both suction and delivery (Type PTFE D = delivery). Working pressure up to 16 bar, burst pressure > 64 bar. Temperature range from - 30° up to + 150° Celsius (depending on medium). Steaming out for cleaning and sterilisation permissible up to 150° C, max. 30 min. Meets EN 12115. FDA und USP Class VI conform according EC regulations 1935/2004 and 10/2011.

ROTEX 80.16

Rubber Expansion Joint suitable for permanent use with hot heating water, cooling water and hot air. Approved according to DIN up to 100° C by 10 bar and up to 110° C by 6 bar. Temperature range (depending on medium) - 40° C up to + 130° C, temporarily up to + 150° C. Electrically dissipative

NB-ZVF 50 SR, ER 583 PTL, HD-C 38

Nozzle boot f. ZVF 50 with additional spout retainer

Requirements to a Hose

(English)

ZVG 2 EURO UL nozzle for L.P. Gas / Autogas

with EA 866 scuffguard black and LPG 16 S hose assembly orange

Heating oil delivery: HD 38 reel hose

Vehicle refuelling Korea with LPG (L.P. Gas, Autogas, Propane)

ZVG 2 K nozzle, LPG 16 hose assembly

Rail tanker toploading, TW 100 hose assemblies

ZVA Slimline 2, black, guard 3 - side view
