LNG Refuelling
LNG Safety Break for installation on LNG dispensers SB-LNG FL-J
HD-C Neon, large reel, VK 100 Ms, MB 100 Al
ELAFLEX Hamburg
Hose assemblies, marking after testing on the fitting
Cargo loading of a tanker with petroleum based products; FHD hose assembly with new longitudinal stripe to avoid torsion
Picture courtesy of Macoil International, Gibraltar
Slimline 21 hose assembly with non reattacheable female coupling M 21-1" NR
VC 75-3" SS / SS
Spannloc threaded hose coupling with BSP male thread / Spannloc of stainless steel
VR Hose Reel Spring Rewind, ZVA Slimline 2 GR blue
for active Vapour Recovery (VR) for gasoline fuels
DCC Dry Cryogenic Coupling for LNG
Coupling process
ZVA Slimline 2 nozzles, ESB 16 Safety Breaks, Slimline hose assemblies
Paraguay
ZVF 50 UL91 overwing refuelling
UL 91: new unleaded aviation fuel - identification colour green
MKX 80 Ms, coupling hose assembly
HB hot bitumen hose - loading road tanker
FWS composite hoses / hose assemblies
Type FWS PP with female threaded fitting, Type FWS PTFE with stainless steel flange
ELAFLEX Hamburg
Nozzle stock, ZVA Slimline 2 GR
Urea solution filling of a car: ZVA LV for AdBlue®
ZVF 25 for aircraft refuelling
dust cap and ground cable assembly
SFC 38 SSE
Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)
Construction site / on site refuelling:
ZVA 500 manual bulk nozzle
ZVA 25
HIFLO-Automatic nozzle DN 25 (1"), flowrate up to 140 litres/min.
ERV-GS
"Yellow Steel" Rubber Expansion Joints / ship engine room; Netherlands
Cabinet of road tanker:
MK 80-32 TW coupler with bent lever, VB 80 P dust plug
Elaflon Plus FEP 75, MK-A 80 SS
Loading and unloading of chemicals. TW coupling with active safeguard lever
ERV SR:
ERV with inner protection sleeve of stainless steel AISI 316 Ti to prevent abrasion of the rubber liner, i. e. for media containing abrasive components or to avoid cavitation. Please note : The nominal bore is reduced.
Marine bunkering and cargo hoses
ship to shore bunkering
Ship bunkering loading and unloading, Hose Reels, HD hose, ZV 500
Bunkerboat
MK-A 80 SS
MK 80 SS with active safeguard lever
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Assembling ZVA components
ZV 500
High performance manual operated dispensing nozzle with 'TW' coupling MK 50 for Diesel, fuel, oils, petroleum
Alternative fuels: DME Dimethyl Ester
DGC Dry Gas Coupling, EFL 16 Fluorline hose assembly
L.P. Gas rail tanker
loading and unloading with DGC Dry Gas Couplings, LPG hose assemblies. Vehicle side: DGC-V male couplings with flange
