ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Swivel assembling
GasGuard LPG nozzle GG30
LPGas nozzle with Bayonet connection according to EN 12806 - 2003 for the filling of commercial and passenger Autogas vehicles as well as mobile and small stationary storage tanks with propane and butane. New : 4-slot design to facilitate connection of the nozzle to the vehicle fill point. New nose piece design to reduce the released gas upon valve closure, incorporating improved gas release method to minimise the risk of splash back.
ZVA Slimline 2 nozzles, ESB 16 Safety Breaks, Slimline hose assemblies
Paraguay
ZVA Slimline 2, dispenser
H2 Hydrogen
H2 25 D Hydrogen hose
ZVA LV for AdBlue®
Urea solution filling of cars and light transporters
ERV-R 200x175.16 ZS 4
Red Band Rubber Expansion Joint, special length 175 mm, with "ZS" limiter (tie rods with outer limitation in rubber bushings)
DDC-V 50 SS
MannTek Dry Disconnect Coupling, DN 50, stainless steel, with BSP thread connection
Swivel Flange and hose tail of stailess steel
SF 63.16 SS
IBC unloading
Female hose coupling MC 38-S60 SS (with Spannfix clamps). Direct connection of a hose assembly to the IBC.
ZVF 25 overwing refuelling
Dantec Production hose
Composite hoses: hose with customer braning, application of outer helix
MK 80-90 SS; MK coupling stainless steel with bent lever 90°
TW coupling with bent lever: For any application it should be checked that the lever can be arrested as shown even if there is tight space. Elaflex offers bent levers for all MK couplers.
ERV-G AF
Suitable for piping systems of aviation refuelling or dispensing vehicles in accordance to EN ISO 1825/EI 1529. Suitable for all aviation fuels.
Urea solution for cars and light transporters: ZVA LV for AdBlue® nozzle
ZVA Slimline 2, dispenser
GasGuard LPG nozzle GG1E
eoconomic type for industrial refueling / attended refueling. Release volume on valve closure: 1,9 cm³.
LNG Refuelling
LNG Safety Break SB-LNG VL und SB-LNG FL
UTL 50 universal chemical hose assembly and TW female coupler MKC 50 SS
TW Couplings with Isolation for electronic Cross-Over Prevention Systems
see Information 4.12
SFC 38 SSE
Swiveling flange hose coupling with Spannfix clamps. Material: stainless steel with universally resistant PFA coating (red)
ELAFLEX Hamburg
Certificate pressure test
Elaflex hose assemblies, nozzles and Rubber Expansion Joints for the chemical industry
Cabinet of road tanker:
MK 80 with VB 80 ADR SS (plug with pressure relief)
FWS composite hose / hose assembly
Type FWS PTFE with male threaded fitting VPH-SS
Urea loading of a petrol station tank
UTS hose assembly, DDC-M 50 SS Dry Disconnect coupling
V 16-1" cr
Male ferrule hose coupling EN 14424, reusable. Slimline 16 hose, blue.
Road tanker for heating oil delivery, HD hose assembly, ZV 500 nozzle, MK 80 Ms coupler with VB 80 P dust plug
ZVA Slimline 2 GR
Automatic nozzle with vapour recovery, flowrate up to 45 l / min.
ELAFLEX Hamburg
Coax hose assembling, colours
