ZVF 50 JET for aircraft refuelling
ELAFLEX Hamburg, stock bellows
ERV-G
Ship engine room: 2 Yellow Band Expansion Joints mounted together for extra permissable movement
Elapharm EPH 25 with DIN 11858 fitting, free of dead spaces
ELAFLEX Hamburg
Assembling VSRV bolted vacuum support ring
Chemopal 50 mW
Chemopal chemical hose DN 50 with helix
LNG ship bunkering
DCC 100 Dry Cryogenic Coupling, CBC 100 PERC Cryogenic Breakaway Coupling
Oasis 3/4" Ball Valve for CNG
Oasis FV103 45° Fill Valve with NC 203 P30 Nozzle, for CNG
UTS hose assembly
Colour production plant
SG-COAX_Al
Sight Glass, to EN 13617-1, for ZVA Slimline 2 GR with vapour recovery. Installation between petrol station nozzle and hose assembly, or mounting on the dispenser. For the visual control of bubble-free dispensing and fuel colour (e. g. for premium fuels). Suitable for all standardised fuels.
Underwing refuelling, HD-C
Aircraft dispenser, pit
Adapters / couplers for vehicles fighting dangerous goods incidents:
Adapters Foodstuff Couplings to DIN 11851 Female Rd 78 x 1/6 SS x VK 50 SS/Vi, Male Rd 78 x 1/6 SS/Vi x MK 50 SS/Vi
CNG Safety Break
SB-CNG FLVL-S
Slimline 19 black
Quality petrol pump hose for gasoline and diesel fuels. Also suitable for fuels with ethanol content up to E 85 and Biodiesel up to B 30 (BIO Type up to B 100). Meets weights and measures regulations, see overleaf. Cold flexible down to - 30° C / - 22° F (LT-type down to - 40° C / - 40° F). Corresponds to EN 1360.
Rail tanker unloading of petroleum based products
LTW hose assemblies; Poland
ERV VSRV:
ERV with bolted vacuum support ring. For maximal vacuum resistance of the selected ERV. Bolted ring in stainless steel AISI 316 Ti.
ELAFLEX HIBY Tanktechnik, Production Plettenberg / Germany
Plettenberg factory 2
CBC-PERC 100
Cryogenic Breakaway Coupling "PERC" for LNG after pneumatic separation
Manufacturing ERV flanges
AMK-St 38 SSE
Camlock female coupler, hose tail for assembling with Spannfix or Spannloc. Material: stainless steel with universally resistant PFA coating (red)
Hose assembly for L.P. Gas
LPG 50, DGC-M 50 with special handle, adapter DGC 50 x 3 1/4" ACME
Heating oil delivery: ZV 400 nozzle, HD reel hose
Construction of ELAFLEX composite hoses type FWS
Sectioned view of a composite hose, denomination of the components (German)
Simultaneous Refuelling/Filling of Diesel and AdBlue®
Picture 1
Rail tanker unloading of petroleum based products
Plant side: FWS PP St/St composite hoses, SG 3" Sight Glasses
MK 80-2" IG
TW female coupler, brass, with reduced female thread (special type)
Unloading chemical road tanker
Tecnopal hose assembly, DDC Dry Disconnect Coupling, Guillemin adapter
MK 80 SS, TW couplers stainless steel
